Agentic work, governed

ChartworkAI

The repository-native governance layer for projects that use AI agents.

Keep scope, authority, decisions, handoffs, and phase gates intact across runtimes, sessions, and teams.

Start the guide View on GitHub

$pip install chartworkai

Repository-nativeState survives the chat.

Runtime-agnosticUse any agent or stack.

VerifiableCompliance is executable.

Start here

One playbook, from initialization to phase close.

Implementation Guide

A single, do-this playbook for running any project with ChartworkAI. Readable top-to-bottom by a person or an AI agent. Deeper detail lives in the docs this guide points to (README.md, INITIALIZATION_GUIDE.md, SOP.md, profiles/, extensions/, PORTABILITY.md).

---

0. The mental model (read this first)

• You + your AI assistant together are the Orchestrator. There are no separate programs.
• "Agents" are roles your assistant plays one at a time — you instantiate one by pasting its System Prompt from AGENTS.md plus a dispatch ticket.
• All project state lives in version-controlled Markdown, never in chat. The repo is the memory and the contract — so any new session, teammate, or different AI assistant resumes by reading files.
• Definition of "installed/healthy" = ./scripts/check_framework_compliance.sh . passes. That checker is the ground truth throughout.

The loop, in one sentence: read state → propose ONE dispatch → the agent produces an artifact + a handoff → file any decisions → update the plan → repeat; at phase boundaries, run the verify command and file a reproducibility report.

---

1. Pick the generic core, a preset, or a custom profile

Running chartworkai init without a profile installs the project-agnostic generic core. The six named profiles are optional presets, not a closed list of project categories. A profile decides which artifacts are required and what "reproducible" means.

Profile	Deliverable	Data contracts	"Reproducible" means
generic	a project-defined deliverable	not required	the project-defined validation commands pass
data-science	reproducible analysis / report	required	byte-identical rebuild from raw
software-app	running / deployable software	not required	build + tests pass
database	a curated dataset	required	deterministic rebuild + quality baselines
competition-ml	a scored submission	required	submission regenerates from a recorded run
investigation	evidence-backed findings	not required	every claim traces to an archived source at an evidence tier
deployed-service	a deployed service + infrastructure	not required	config + image digest + job URI trace a release

Each built-in profile has a spec in profiles/ covering its required artifacts, verify contract, and default roles. For another project type, copy templates/custom_profile.template.json, set extends to generic or one of the six presets, and define project-specific roles, required artifacts, scaffold directories, and validation commands. Custom commands are recorded in the charter but never executed implicitly.

---

2. Bootstrap (one command)

Run from the framework repo root:

Either the CLI (recommended — works from a plain pip install, anywhere):

pip install chartworkai
chartworkai init ~/projects/trip_planner --name "Trip Planner"

Add --profile software-app for that preset, or --profile-file ./my-profile.json for a custom contract.

…or the shell script, run from a clone of this repository:

scripts/init_project_from_framework.sh  ~/projects/trip_planner  "Trip Planner"  trip_planner  software-app

For generic and the six presets, both entry points produce a byte-identical scaffold; CI diffs them on every change. Custom JSON profiles use the Python package because robust JSON parsing is deliberately not reimplemented in POSIX shell.

This creates the canonical operating files (PROJECT_CHARTER.md, AGENTS.md, STATUS.md, TASKS.md, docs/phase_plan.md, decisions/handoffs/domain seeds, and — for data profiles — docs/data/ contracts), copies reference material into _framework_* folders, and runs the compliance check.

The fresh scaffold deliberately fails the check (unfilled {{placeholders}} + the temporary _framework_* folders). That is the graduation gate, not an error.

---

3. Customize (make it yours)

Fill these in. Use the paste-ready prompts in prompts/ to draft each with your assistant.

1. PROJECT_CHARTER.md — the single source of truth. Fill: mission, ≥3 non-goals, the Profile: line, the ## Stack block (declare your verify command — this is your "it works" gate), the phased roadmap, and success criteria. (Draft from a one-paragraph brief with prompts/01_initial_planning.md; build the roadmap with prompts/03_phase_roadmap.md.)
2. AGENTS.md — the roster. Always keep Orchestrator and a QA / Reproducibility role. Rename the Domain Expert for your field. Add a Producer (Data Engineer, or Software Engineer for apps) and any optional roles from agents/_optional/ (e.g. Frontend Engineer, Deployment Engineer). Paste each role's Spec and its System Prompt, and resolve every {{placeholder}}. (Draft with prompts/02_agent_generation.md.)
3. Data contracts (data profiles only) — fill docs/data/data_dictionary.md, lineage.md, watchlist.md. Non-data profiles skip this.
4. docs/domain/README.md — what a new agent must know about your domain.
5. Optional extensions — copy any you want from _framework_extensions/ (external-tracker sync, claims gate, experiment log, assistant primer). See extensions/README.md.

---

4. Graduate (verify = "installed")

./scripts/check_framework_compliance.sh .      # repeat until it says "passed"
rm -rf ./_framework_*                           # delete the temporary reference folders
git init && git add -A && git commit -m "Initialize <project> from ChartworkAI"

When the checker passes, the project is installed and ready to run.

---

5. Operate (the daily loop)

Open your AI assistant in the project repo and run this cycle (full detail in SOP.md):

a. Session start. Read docs/phase_plan.md, the 3 most recent docs/handoffs/, and the open items in TASKS.md. (Or paste prompts/04_orchestration_turn.md — the assistant reads state and proposes the next step.)

b. Dispatch ONE agent with a complete ticket:

Dispatch → <Role>
  Inputs:    <exact files/paths to read>
  Output:    <exact files/paths to produce>
  Done when: <one-sentence, checkable test>
  Escalate:  <condition> → <which agent/authority>
  Handoff:   → <next agent>

c. The agent produces the artifact + a handoff note — the only currency between agents:

docs/handoffs/YYYY-MM-DD_<agent>.md
  What was produced · Where it lives · Known limitations · How to verify · Next agent

(Within a phase, a one-line "Findings" under the task in TASKS.md is the lightweight equivalent; write a full handoff file at phase boundaries. Draft with prompts/06_handoff_writeup.md.)

d. File any real decision (anything that changes scope, schema, a convention, or interpretation) as a dated, authority-stamped file. Use ID namespaces:

docs/decisions/YYYYMMDD_<NS>###_<short_title>.md      NS ∈ { DEC, DQ, SC, MD }
  Date · Authority · Status · Context · Ruling · Rationale · Consequences

Link it from PROJECT_CHARTER.md §Decision log. (Draft with prompts/05_decision_capture.md.)

e. Update the living docs in place — move the task in TASKS.md, refresh docs/phase_plan.md. Never append duplicate sections. You can rebuild the plan from current state any time:

./scripts/generate_phase_plan.sh .

Repeat a→e, one dispatch at a time.

---

6. Close a phase

1. Run your verify command (from ## Stack) on a clean checkout.
2. File docs/reproducibility/phase_<N>.md (what was verified + the result).
3. Tick the charter's exit criteria, post a STATUS.md entry, promote to the next phase.
4. Optionally run a retro with prompts/07_reflection.md.

---

7. Keep it healthy

Run ./scripts/check_framework_compliance.sh . regularly. It is your drift alarm — it fails on: unresolved placeholders, missing required files, duplicate headings, a TASKS.md that isn't a checkbox queue, a stale or bloated STATUS.md/phase_plan.md, decision files that break the namespace pattern, leftover _framework_* folders, and tool-specific leaks (assistant names / slash-commands) in core docs. Fix what it flags. Run prompts/07_reflection.md at each phase boundary.

---

Quick reference

Canonical files

File	Purpose
PROJECT_CHARTER.md	Single source of truth: mission, non-goals, profile, ## Stack, phases, success criteria, decision log
AGENTS.md	Roles-as-contracts: shared conventions + per-agent Spec & System Prompt
docs/phase_plan.md	Current phase, active agents, exit criteria, dispatch queue (regenerable)
STATUS.md	Weekly/milestone pulse — newest entry on top, keep it short
TASKS.md	Dispatch queue — checkbox bullets, one ## In Progress
docs/decisions/	Dated, authority-stamped rulings (DEC/DQ/SC/MD-###)
docs/handoffs/	Inter-agent handoff notes (the currency)
docs/domain/	Domain knowledge the Domain Expert maintains
docs/data/	(data profiles) data_dictionary, lineage, watchlist
docs/reproducibility/	Phase-close verify reports

Commands

scripts/init_project_from_framework.sh <dir> "Name" slug [profile]   # generic/preset bootstrap
./scripts/check_framework_compliance.sh .                            # verify / "installed"
./scripts/generate_phase_plan.sh .                                   # rebuild phase_plan from state

pip install chartworkai                                                # or use the CLI
chartworkai init <dir> --name "Name"                                  # generic bootstrap
chartworkai init <dir> --name "Name" --profile-file <file>            # custom bootstrap
chartworkai check . [--json] [--strict]                                # verify / "installed"
chartworkai plan .                                                     # rebuild phase_plan from state
chartworkai state .                                                    # where the project stands
chartworkai mcp                                                        # serve to an AI assistant

Let your assistant enforce it (MCP). Instead of remembering to run the checker, point your assistant's MCP config at chartworkai mcp:

{ "mcpServers": { "chartworkai": { "command": "chartworkai", "args": ["mcp"] } } }

It then has chartworkai_check (health), chartworkai_state (phase, tasks, blockers, recent decisions/handoffs), chartworkai_file_decision (auto-numbered per namespace), and chartworkai_file_handoff. The loop in §5 becomes something the assistant does natively — read state, dispatch, record the decision, write the handoff — instead of something you have to police.

Prompts (prompts/) — paste into your assistant at the right moment 01 draft the charter from a brief · 02 draft the roster · 03 build the phase roadmap · 04 "what's the next single dispatch?" · 05 capture a decision · 06 write a handoff · 07 run a reflection retro.

---

Worked example — "Trip Planner" (software-app), compressed

# 1. Bootstrap
scripts/init_project_from_framework.sh ~/projects/trip_planner "Trip Planner" trip_planner software-app

# 2. Charter §Stack (filled)
Profile: software-app
- Build command:  pnpm build
- Test command:   pnpm test
- Verify command: pnpm build && pnpm test

# 3. Roster (AGENTS.md): Orchestrator · Travel Product Owner (Domain Expert) ·
#    Software Engineer · Frontend Engineer · QA Engineer

# 4. Graduate
./scripts/check_framework_compliance.sh .   →  "passed";  rm -rf ./_framework_*;  git commit

# 5. First dispatch
Dispatch → Software Engineer
  Inputs:    PROJECT_CHARTER.md §Stack, docs/domain/README.md
  Output:    src/itinerary/ + tests
  Done when: GET /itinerary returns a 3-day plan for a city; `pnpm test` green
  Escalate:  trip-scoring rule unclear → Travel Product Owner
  Handoff:   → QA Engineer
# → produces src/, then docs/handoffs/2026-06-13_software_engineer.md
# → decision filed: docs/decisions/20260613_SC001_sqlite_for_v1.md

---

If you are an AI agent implementing this autonomously

1. Confirm the profile and the verify command from PROJECT_CHARTER.md. If absent, ask the human or infer from the stack, then record it.
2. Run ./scripts/check_framework_compliance.sh .. Treat every failure as a task. Do not proceed to domain work until placeholders are resolved and the structure is in place.
3. Act as Orchestrator: read docs/phase_plan.md + recent handoffs/decisions, then propose and execute exactly one dispatch using the ticket format in §5b. Do not do domain work as the Orchestrator — adopt the specialist role (its System Prompt in AGENTS.md) for that.
4. For each completed dispatch: write the artifact, write a handoff (§5c), file any decision (§5d), update TASKS.md + docs/phase_plan.md in place.
5. Never invent state in chat. If it matters, it goes in a file. If two files disagree, the charter wins and you file a decision to reconcile.
6. At a phase boundary: run the verify command, file docs/reproducibility/phase_<N>.md, then promote the phase.
7. Re-run the compliance checker before declaring any milestone done.
